Introduction to Bearings

Are ABEC 7 Bearings Good?

Are ABEC 7 Bearings Good?

  • 2020/08/17

ABEC 7 bearings would be very fast and smooth, the price will be higher.

Here Are skate bearing procesion ,from low to high for your reference.



  • ABEC 1 equal to ISO P0
  • ABEC 3 equal to ISO P6
  • ABEC 5 equal to ISO P5
  • ABEC 7 equal to ISO P4
  • ABEC 9 equal to ISO P2



There are a number of factors covered by the abec bearings grades, but to give you an idea we will just examine one of these factors-the eccentricity (out of roundness) of the track in the inner ring. For an ABEC 1 (lowest grade ) bearing, the maximum eccentricity allowable is 0.0075 mm (0.000295"). This is quite precise-more than precise enough for skates and skateboards. The figures for other grades are:


ABEC3: 0.005 mm (0.000197")

ABEC5: 0.0035 mm (0.000138")

ABEC7: 0.0025 mm (0.000098")

ABEC9: 0.0012 mm (0.000047")


ZZ BEARINGS is Skateboard Bearing Wholesale Suppliers ,we can produce different grade skate roller bearings for you .

Roller Skates Bearings
Roller Hockey Skate Bearings
