35*65*35 mm DAC3506535 wheel bearings can used for Chery wheel bearing .
item no.:
DAC3506535lead time:
3-7 DAYSproduct orgin:
Chinashipping port:
NINGBO ,GUANGZHOU ,QINGDAO,SHANGHAIMOQ:
100
| Bearing Modle | DAC3506535 |
| Type |
DAC3506535 bearings |
| Description | used for motor vehicles |
| Dimensions |
35*65*35 mm |
| d | 35 mm |
| D | 65 mm |
| B | 35 mm |
| Service | Neutral/OEM/As per your request |
| Package | Single box/Barrel |
Position:Front Axle
Outer Diameter: 80mm
Inner Diameter :42mm
Height :45mm
Chery Front & Rear Wheel Hub Bearing
Material: Chrome Steel / Bearing Steel (GCr15)
Retainer/Cage: Superior Engineering Plastic.
Typical Application:
Chery, Geely, Great Wall, Chang'An, Peugeot, Honda
We can produce other DAC wheel hub bearings:
| Codes | Dimension(mm) | Cr.(KN) | Cor.(KN) | |||
| d | D | B | R (rsmin) | |||
| DAC2505237C | 25 | 52 | 37 | 2.5 | 28.5 | 21.9 |
| DAC2505237-2RS | 25 | 52 | 37 | 2.5 | 28.5 | 21.9 |
| DAC2505242C | 25 | 52 | 42 | 3 | 31.5 | 22.9 |
| DAC2507243C | 25 | 72 | 43 | 3 | 48.6 | 41.9 |
| DAC2806142 | 28 | 61 | 42 | 2.5 | 37 | 30 |
| DAC3006037 | 30 | 60 | 37 | 2.5 | 37 | 30 |
| DAC3405824 | 34 | 58 | 24 | 2.8 | 22.3 | 19.8 |
| DAC3406237 | 34 | 62 | 37 | 2.5 | 37.4 | 31.6 |
| DAC3406437D | 34 | 64 | 37 | 2.5 | 37.4 | 31.6 |
| DAC3406637C | 34 | 66 | 37 | 2.5 | 37.4 | 31.6 |
| DAC3406737C | 34 | 67 | 37 | 3.3 | 42.5 | 36.1 |
| DAC3406737YA | 34 | 67 | 37 | 3.3 | 42.5 | 36.1 |
| DAC3406437E | 34 | 64 | 37 | 3.3 | 42.6 | 35.7 |
| DAC3506228C | 35 | 62 | 28 | 2 | 29.5 | 27.2 |
| DAC3506240C | 35 | 62 | 40 | 3 | 37.4 | 31.6 |
| DAC3506535 | 35 | 65 | 35 | 2.5 | 36.8 | 31 |
| DAC3506633C | 35 | 66 | 33 | 2.5 | 42.6 | 35.7 |
| DAC3506637C | 35 | 66 | 37 | 2.5 | 37.4 | 31.6 |
| DAC3506837C | 35 | 68 | 37 | 3.6 | 42.5 | 36.3 |
| DAC3506840C | 35 | 68 | 40 | 3 | 46.4 | 37.9 |
| DAC3506842C | 35 | 68 | 42 | 3 | 46.4 | 37.9 |
Bearing 30BWD07 also same as the item DAC3060W This bearing with bore diameter is 30 mm,outer diameter 60.03mm the width 37mm can be waidely use in different cars such as Volvo
wheel hub bearing 43560-26010, 54KWH02 with size Inner Diameter: 53 mm*Outer Diameter: 90 mm*Width: 60 mm is use for Front Axle of Hiace IV Wagon.
26x55.5x43mm DAC2656 Wheel Bearing can used for Hyundai Eon.
Tapered roller bearings 4T-CRI-0569CS83/5A with size Bore Diameter (mm) : 27*Outer Diameter (mm) : 52*Width (mm) : 45 are widely used for auto spare parts.
54*132*51mm 54KWH01 Wheel Hub Bearings can used for Toyota front axle ,we can provide sample for you to test .
35*65*35 mm DAC35650035Wheel Hub Bearings can used for Renault ,Chrysler ,Peugeot,we can provide sample for you to test .
