Standard JB/T2300-1999
Drawing Number Composition
 |
|
 |
Material: 42-42CrMo 40-40Cr 50-50Mn |
| Installing Hole Type: 0- Through holes on the inner and outer rings 1- Thread holes on the inner and outer rings 2- Thread holes on the inner ring, through holes on the outer ring 3- Thread holes on the outer ring, through holes on the inner |
|
| No meaning digit, only avoid code confusion. | |
| Installing Match Type: 0-Standard type without Break 1-Standard type with Break 2-Special type |
|
| Raceway Diameter | |
| Diameter of the rolling element | |
| Gear: 0-Toothless 1-External spur gear,smaller modle 2-External spur gear,bigger modle 3-Internal spur gear,smaller modle |
|
| Design Type: 01-Single Row Four Point Contact Ball Slewing Bearing 02-Double Row Different Balls Slewing Bearing 11-Single Row Cross Roller Slewing Bearing 13- Three Row Roller Slewing Bearing |
If you can not find a suitable bearing in our production lists,pls send the drawing to us or download this for [ Type Selection of Slewing Bearing ] , finish it and send it to us for select the bearing.
